GLC Coating Machine for Graphite-Like Carbon Functional Coating, CGVAC Manufacturer
CGVAC GLC coating machines are designed for depositing Graphite-Like Carbon (GLC) films with low friction, high adhesion and excellent chemical stability. The equipment provides advanced functional coating solutions for mechanical components, electronic parts, medical devices and premium consumer products requiring enhanced durability and surface performance. Contact us for a custom vacuum coating machine solution!
Technical Parameters:
| Target Materials | Metals, alloys and various industrial components. |
| Coating Technology | Vacuum plasma deposition technology |
| Functional Coatings | GLC and other hard & wear-resistant coatings. |
| Core Components | Arc target, control system, pump |
| Application | Mechanical components, electronic parts, medical devices and premium consumer products, etc. |
| Customization | Customized size, target material, color, fixture design, and process plan |
| Service | Mechanical/sample test reports, video outgoing inspection, and technical guidance. |
Product Detail
Specifications of GLC Coating Machine:
| Model Number | Dimension DxH (mm) | Ultimate Vacuum (Pa) | Pumping Time (Min) | Targets (PCS) | Total Power (KW) |
| DZ1214 | 1200*1400mm | ≤8×10⁻⁴ | ＜5 | 10 | 50 |
| DZ1416 | 1400*1600mm | ≤8×10⁻⁴ | ＜5 | 14 | 60 |
| DZ1618 | 1600*1800mm | ≤8×10⁻⁴ | ＜5 | 21 | 80 |
| DZ1818 | 1800*1800mm | ≤8×10⁻⁴ | ＜5 | 28 | 110 |
| DZ2118 | 2100x1800mm | ≤8×10⁻⁴ | ＜5 | 32 | 120 |
*Equipment specifications can be customized according to customer requirements. Height or depth can range from 600mm to 10000mm.
Features of GLC Coating Machine:
Advanced GLC Functional Coating Technology: Designed specifically for Graphite-Like Carbon (GLC) film deposition, the machine enables the production of advanced carbon-based coatings that combine graphite-like self-lubrication with excellent adhesion and film uniformity.
Low-Friction & Self-Lubricating Coating Capability: The equipment produces GLC coatings with excellent lubricating performance, reducing friction and wear on mechanical components, especially in oil-free, water-lubricated and demanding operating environments.
Low-Stress Deposition with Strong Film Adhesion: Optimized coating processes ensure low internal stress and strong adhesion, preventing cracking or peeling while maintaining long-term durability on complex components.
Low-Temperature Coating Process: The GLC coating system supports low-temperature deposition, making it suitable for precision parts, alloys and heat-sensitive substrates while preserving the original material properties.
Stable Vacuum Deposition System: Equipped with advanced vacuum control and plasma generation technology, the machine ensures uniform carbon film thickness, consistent coating quality and reliable batch production.
Intelligent Process Control System: The automatic control system allows precise adjustment of key coating parameters, including vacuum conditions, deposition cycles and process settings, ensuring stable and repeatable coating results.
Customized Equipment Configuration: CGVAC provides customized chamber sizes, fixture designs and equipment configurations according to different workpiece dimensions, production requirements and application needs.
GLC Coating Performance：
| Performance | Typical Value | Benefits |
|---|---|---|
| Surface Hardness | HV 400-700 | Improves wear resistance and surface durability |
| Friction Coefficient | 0.08-0.15 | Provides excellent self-lubrication and reduces friction loss |
| Internal Stress | 0.5-1.5 GPa | Ensures strong adhesion and reduces coating cracking |
| Electrical Resistivity | 10⁻⁴-10⁻² Ω·cm | Suitable for conductive protection applications |
| Deposition Temperature | Room Temperature – 120℃ | Compatible with heat-sensitive substrates |
| Chemical Stability | Excellent | Provides corrosion and chemical resistance |
Applications of GLC Coating Machine
Why Choose CGVAC, Professional PVD Vacuum Coating Machine Manufacturer
High Production Efficiency
Excellent Film Quality
Intelligent Automation
IndepFull-System In-House R&D
Customization Support
Technical Service
Contact Us
FAQ
- Q: What types of materials can PVD coating machines process?
A: Sanitary ware, jewelry &beads, daily ceramics, stainless steel, glass, plastics, and electronic & optical components for both decorative and functional coatings.
- Q: Can the CGVAC PVD vacuum coating machines be customized?
A: Yes. We offer standard and fully customized solutions, including chamber size, coating process, capacity, and color etc.
- Q: Do you provide installation and training?
A: Yes. We provide global on-site installation, operator training, and remote technical support.
